1 Metre Classic Wrap Straight Silicone Hoses

1 Metre Classic Wrapped Straight Silicone Hose

✅ 1 Metre Long ✅ Fuel & Oil Safe ✅ Classic Wrap Finish

1 Metre Classic Wrapped Straight Silicone Hose Motor Vehicle Engine Parts Auto Silicone Hoses 13mm Black

1 Metre Classic Wrapped Straight Silicone Hose Motor Vehicle Engine Parts Auto Silicone Hoses 16mm Black

1 Metre Classic Wrapped Straight Silicone Hose Motor Vehicle Engine Parts Auto Silicone Hoses 19mm Black

1 Metre Classic Wrapped Straight Silicone Hose Motor Vehicle Engine Parts Auto Silicone Hoses 25mm Black

1 Metre Classic Wrapped Straight Silicone Hose Motor Vehicle Engine Parts Auto Silicone Hoses 32mm Black

1 Metre Classic Wrapped Straight Silicone Hose Motor Vehicle Engine Parts Auto Silicone Hoses 35mm Black

1 Metre Classic Wrapped Straight Silicone Hose Motor Vehicle Engine Parts Auto Silicone Hoses 38mm Black

1 Metre Classic Wrapped Straight Silicone Hose Motor Vehicle Engine Parts Auto Silicone Hoses 45mm Black

1 Metre Classic Wrapped Straight Silicone Hose Motor Vehicle Engine Parts Auto Silicone Hoses 51mm Black

1 Metre Classic Wrapped Straight Silicone Hose

✅ 1 Metre Long ✅ Fuel & Oil Safe ✅ Classic Wrap Finish

SKU

WSH013-ASH

Brand

Auto Silicone Hoses

Application

Fuel & Oil Lines, Coolant Systems, Radiator & Water

Temperature Range

-60°C to +180°C

Internal Diameter

13mm

Internal Diameter Inch

1/2"

Outside Diameter

22mm

Outside Diameter Inch

7/8"

Main Body Length

1 Metre

Centre Line Radius

Bend Radius

130mm

Number Of Plys

Leg Length

Max Coil Length

1 Metre

Wall Thickness

4.5mm

Surface Finish

Wrapped Matte

Inner Layer Material

Flouro Silicone

Outer Layer Material

VMQ Silicone Rubber

Material

Reinforcement

Polyester Braid

Conforms To

SAEJ30R6

Colour

Black

Bursting Pressure

27.0 Bar

Working Pressure

8.33 Bar

Safety Factor

3 x Working Pressure

Weight

0.30 kg/m

Band Width

Roll Length

Roll Width

Thickness

Tensile Strength

Overall Length

Filter Top Width

Filter Bottom Width

Hose Flat Width

Download Datasheet

Your custom code is here (HTML, JavaScript, CSS, Shopify Liquid)

QUANTITY:

£17.73

Sale {price}%

£14.18 ex VAT

ADD HOSE CLIPS & JOINERS.

Selected OD (Outside Diameter):

22mm

Match Hose OD To Clip Size Range

DELIVERED TO YOUR DOOR.

Free standard delivery when you spend £40!

COLLECT IN STORE.

Pickup Available At Silicone Hose UK.

Collect In 1 Hour

1 Metre Classic Wrapped Straight Silicone Hose

Internal Diameter: 13mm, Color: Black

Silicone Hose UK

Pickup Available, collect in 1 hour

HolmeBank Business Park, Station Road
Unit 5
Mirfield WF14 8NA
United Kingdom

+441924496111

BUY NOW. PAY LATER.

SKU

WSH013-ASH

Brand

Auto Silicone Hoses

Application

Fuel & Oil Lines, Coolant Systems, Radiator & Water

Temperature Range

-60°C to +180°C

Internal Diameter

13mm

Outside Diameter

22mm

Main Body Length

1 Metre

Centre Line Radius

Bend Radius

130mm

Number Of Plys

Leg Length

Max Coil Length

1 Metre

Wall Thickness

4.5mm

Surface Finish

Wrapped Matte

Inner Layer Material

Flouro Silicone

Outer Layer Material

VMQ Silicone Rubber

Material

Reinforcement

Polyester Braid

Conforms To

SAEJ30R6

Colour

Black

Bursting Pressure

27.0 Bar

Working Pressure

8.33 Bar

Safety Factor

3 x Working Pressure

Weight

0.30 kg/m

Band Width

Screw Type

Pack Quantity

Band Thickness

Clip Diameter

Download Datasheet

Description

Introducing our Classic Style Fluro-Lined Silicone Hose, designed for high-performance applications where reliability is paramount. This hose features a temperature range of -60°C to +180°C, making it suitable for a variety of environments. With an internal diameter of 13mm (1/2") and an outside diameter of 22mm (7/8"), it’s ideal for intermittent transfer of fuel or oil.

Constructed with a fluro silicone inner layer and VMQ silicone rubber outer layer, this hose provides exceptional chemical resistance and flexibility. The polyester braid reinforcement ensures durability, conforming to SAEJ30R6 standards. With a bending radius of 130mm and a wall thickness of 4.5mm, it is engineered to maintain its shape under pressure.

This hose boasts a bursting pressure of 27.0 bar and a working pressure of 8.33 bar, with a safety factor of 3 times the working pressure. The wrapped matte surface finish adds to its classic aesthetic while enhancing grip and handling.

Designed for seamless integration, this silicone hose can be easily used in systems with hose clips and aluminium joiners, ensuring secure and leak-free connections. Versatile for automotive, industrial, and custom applications, this silicone hose ensures dependable performance wherever it’s needed.

Returns

For further details pertaining to our return policy, kindly refer to our dedicated Returns & Warranties page.We offer 30 day return policy on 99% of our items, some are considered Custom made products (This would include Alloy Joiners, Alloy Connector & Silicone Couplers as these are made specifically for each order and are classed as a 'tailor-made' product). These are non returnable.

For further details pertaining to our return policy, kindly refer to our dedicated Returns & Warranties page.

Gallery

POPULAR PRODUCTS.

Filtech Foam Air Filter

Specifications not available

More Options Available

Starting From
£38.92

51mm OD Aluminium Beaded Alloy Hose Joiner

Conforms to T6063

20 Lengths

Starting From
£7.34

Poor customer service

Brought a hose over a week ago sent email no response phoned up can’t help and still haven’t received parcel just poor product great but wouldn’t purchase from this company again as you can’t speak to anyone

Just the ticket!

Was looking for a classic look hose to replace my VW bus intake couplers with and the 38mm ID are just the ticket to look close to stock and not flashy or too “performancy”!

FREQUENTLY ASKED QUESTIONS.

Can Silicone Hoses Be Used For Fuel/Oil?

If you intend to use silicone hoses for fuel or oil applications, it is recommended to use Fluorolined Silicone, hoses are specifically designed to offer enhanced resistance to a wider range of chemicals, including fuels and oils.

Will Silicone Hose Stretch?

Silicone hoses are known for their flexibility and elasticity, which allows them to stretch to some extent. However, the degree to which a silicone hose can stretch depends on various factors, including its design, thickness, and the specific type of silicone used in its construction. We advise that our hoses can stretch a maximum of 3mm on the diameter.

Can Silicone Hoses Be Used For Coolant?

Yes, silicone hoses are commonly used for coolant applications. Silicone hoses are well-suited for coolant systems in various industries, including automotive, marine, and industrial applications.

How Long Do Silicone Hoses Last?

The lifespan of silicone hoses can vary depending on several factors, including the quality of the material, the specific formulation of the silicone, the environmental conditions, and the type of application. In general, silicone hoses are known for their durability and longevity, and they often outlast traditional rubber hoses in many applications.

What is the temperature rating of silicone hoses?

The temperature rating of silicone hoses is typically in the range of -60°C to +180°C (-76°F to 356°F). Silicone hoses are known for their ability to withstand a wide range of temperatures, making them suitable for various applications in industries such as automotive, aerospace, and manufacturing. It's important to note that specific products may have slightly different temperature ratings, so it's advisable to refer to the manufacturer's specifications for precise details on a particular silicone hose.
